1/0 ACSR Diameter Guide: 0.398 in Partridge Specs, Size Chart and Selection

The overall diameter of 1/0 ACSR is 0.398 inches (10.11 mm). In the ASTM B232 bird-name series this size is called Partridge, and it is built as a 6/1 construction: six hard-drawn aluminum strands, each 0.1327 in (3.37 mm) in diameter, wrapped around a single galvanized steel core strand of the same diameter. Because six strands surround one core, the finished diameter works out to exactly three strand diameters, which makes the figure easy to verify on site with nothing more than a caliper.

That single number decides more than people expect. It determines which compression dead-ends and splice sleeves will seat correctly, how much wind and ice load each metre of span collects, and whether the sag-tension file your designer ran actually matches the reel that arrives. The sections below unpack what 1/0 actually measures, how this size compares with its neighbors, and the ordering details that prevent rework.

What 1/0 Actually Measures in an ACSR Conductor

1/0 — spoken as "one-aught" — is an electrical designation, not a physical dimension. For 1/0 ACSR it means 53.5 mm² of aluminum, the material doing the conducting. The steel core adds strength but virtually no conductivity, and the twisted strands leave air gaps between them, so the finished conductor is physically larger than a solid wire of the same AWG size. A solid 1/0 aluminum wire measures 0.325 in (8.25 mm) across; the ACSR version measures 0.398 in — about 22% more diameter for an identical electrical rating.

This is why hardware catalogs list 1/0 ACSR as its own entry, separate from 1/0 all-aluminum or 1/0 copper equivalents. Same ampacity class, but a different outside diameter and different steel content, which means different compression sleeves, installation dies and clamp grooves. Ordering a fitting as plain "1/0" invites a sleeve that was never meant to close over a steel core, and the mistake usually surfaces mid-project with a stringing crew standing idle.

At 1/0 the construction choice is simple: Partridge 6/1 is the standard offering in the B232 bird-name series at this size, so there is only one diameter to track. In the larger kcmil sizes, the same aluminum area can be built with several steel contents, producing several different overall diameters — which is why the diameter figure belongs on the specification sheet for every conductor once sizes grow.

1/0 ACSR Diameter in Context: The Neighboring 6/1 Sizes

Most small ACSR orders are settled within a step or two of 1/0, so the neighboring diameters are worth keeping on one line each. The table below lists the standard 6/1 constructions around Partridge, with nominal values drawn from manufacturer data based on ASTM B232.

Two patterns are worth noting. Stepping from 1/0 to 2/0 adds about 12% to the diameter but about 26% to the aluminum area, so electrical capacity grows faster than visual bulk. Weight rises with the aluminum area rather than the diameter, so it pulls further ahead as sizes grow: 4/0 weighs roughly twice as much as 1/0 while measuring only about 41% more across.

If the choice between steel-reinforced and all-aluminum conductors is still open, our practical AAAC vs AAC vs ACSR comparison guide walks through the mechanical and cost trade-offs in detail.

Where the 0.398 in Diameter Does Real Work

Fittings and hardware

Compression dead-ends, full-tension splices and suspension clamps are sized to a conductor's diameter and stranding, not just its AWG number. A compression sleeve made for 7-strand 1/0 all-aluminum conductor runs roughly 0.03 in smaller on the inside and will not pass over a 0.398 in ACSR surface at all. Insulator ties and clamp grooves behave the same way: a groove cut for the next size up lets the conductor slip under load, while one cut too small gouges the aluminum strands during installation. Writing "1/0 ACSR 6/1 (Partridge)" on the fitting order removes the ambiguity for a few extra words.

Sag, tension and line loading

Designers feed diameter, weight and rated breaking strength into sag-tension calculations. At 10.11 mm, 1/0 ACSR presents a surface that ice builds around as a tube and wind pushes against directly, so both loads scale with the diameter figure. The conductor weighs about 0.214 kg/m (roughly 144 lb per 1,000 ft) and delivers a rated breaking strength in the neighborhood of 5,000 lb (about 22 kN) with utility-grade steel — comfortable for the medium spans of rural distribution, though long road or river crossings often justify a step up. A diameter entered wrongly into the sag file shifts the calculated mid-span curve, and the error only appears when someone measures actual clearances after stringing.

Ampacity and thermal behavior

Current capacity comes from the 53.5 mm² of aluminum; the steel core contributes almost nothing electrically. Published tables place 1/0 ACSR around 230 A under classic assumptions — 75 °C conductor temperature, 40 °C ambient, light wind — and the DC resistance is about 0.527 ohms per kilometer (0.161 ohms per 1,000 ft) at 20 °C. Diameter enters indirectly through surface area: a larger outside diameter sheds heat more readily, which is why two constructions with the same aluminum area can carry slightly different ratings. Comparing ampacity figures without confirming construction is a common way to end up with numbers that were never measured on the same geometry.

Diameter also shapes the clearance conversation. A bare 10.11 mm conductor requires its full phase spacing and vegetation setbacks, so corridors hemmed in by trees or buildings often push utilities toward covered conductors, which keep a similar mechanical footprint but add an insulated jacket rated from 1 kV up to 35 kV.

Aerial Insulated Cable Rated 1kV to 35kVThis XLPE or PE insulated overhead cable suits corridors with limited clearance, adding an insulated jacket rated up to 35 kV while keeping a similar mechanical footprint to bare conductors.View Product →

How to Verify the Diameter on Delivered Reels

Because 1/0 ACSR is bought by electrical size but checked by physical size, a caliper settles most receiving disputes in a minute. A short routine keeps the measurement honest:

1. Measure across the crowns of opposite outer strands with a caliper or micrometer, at least a metre or two from the cut end where the stranding is undisturbed.
2. Take several readings around the circumference and average them; a single reading can sit high or low depending on where the strands happen to rest.
3. Cross-check with a tape wrapped around the conductor: the circumference should read close to 1.25 in (31.8 mm), and dividing that by pi should return roughly 0.398 in.
4. Compare the result against the reel's datasheet rather than another conductor sample, and treat deviations of a few thousandths of an inch as normal manufacturing variation.

What should raise a flag is a consistent gap. A reel averaging near 0.37 in is almost certainly 7-strand 1/0 all-aluminum; a reel near 0.45 in is 2/0 ACSR. Both are useful conductors, but neither is the Partridge on the purchase order, and the mismatch will resurface immediately when the pre-ordered fittings refuse to fit.

Ordering Details That Prevent Rework

A diameter figure alone is not an order. The checklist below turns "1/0 ACSR" from shorthand into a purchase that matches the design file:

1. State the full construction — 1/0 ACSR 6/1 (Partridge) — because size alone invites substitution.
2. Name the governing standard, ASTM B232 for North American practice, and align on the equivalent for projects built to IEC or other national systems before quoting.
3. Confirm the steel grade and the resulting rated breaking strength, since sag-tension design depends on both.
4. Fix the datasheet check figures: 0.398 in (10.11 mm) overall diameter, 0.214 kg/m weight, and about 0.527 ohms per kilometer of DC resistance at 20 °C.
5. Agree drum lengths, reel marking and factory test certificates before production starts, so receiving inspection has something concrete to measure against.
